Name: PRO B650M-P DDR5 MSI - KhabirTech
Price: 29500.00 DZD
Availability: InStock

PRO B650M-P MSI

Compatible with AMD Ryzen™ 8000 / 7000 Series Desktop Processors. Refer to MSI.
Supports DDR5 Memory, Dual Channel DDR5 7200+MHz (OC)
Core Boost: Features a premium layout and digital power design for enhanced core support and performance
Memory Boost: Utilizes advanced technology for optimal data signal purity, performance, stability, and compatibility
High Quality PCB: Constructed with a 6-layer PCB and 2oz thickened copper
Lightning Fast Gaming: Equipped with PCIe 4.0 slots and Lightning Gen 4 x4 M.2 for speedy game performance
2.5G LAN: Enhanced network solution for professional and multimedia use, providing a secure, stable, and fast network connection
AUDIO BOOST: Delivers studio-grade sound quality for an immersive gaming experience
Steel Armor: Protects VGA cards against bending and EMI, ensuring better performance, stability, and durability

SPECIFICATIONS

CHIPSET

AMD B650

MEMORY

4x DDR5, Maximum Memory Capacity 256GBMemory Support DDR5 7200+(OC)
Max. overclocking frequency:
• 1DPC 1R Max speed up to 7200+ MHz
• 1DPC 2R Max speed up to 6000+ MHz
• 2DPC 1R Max speed up to 6000+ MHz
• 2DPC 2R Max speed up to 5400+ MHz

Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports AMD EXPO

ONBOARD GRAPHICS

1x HDMI™
Support HDMITM 2.1, maximum resolution of 4K 60Hz*
1x DisplayPort
Supports DP 1.4, maximum resolution of 4K 60Hz*
1x VGA
Support VGA, maximum resolution of 1920x1200 60Hz*

SLOT

1x PCI-E x16 slot
• Supports x16 (For Ryzen™ 7000 Series processors)
• Supports x8 (For Ryzen™ 7 8700G and Ryzen™ 5 8600G processors)
• Supports x4 (For Ryzen™ 5 8500G processor)
2x PCI-E x1 slot
PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset)

STORAGE

2x M.2
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
4x SATA 6G

RAID

Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices
Supports RAID 0 and RAID 1 for M.2 NVMe storage devices

USB

4x USB 2.0 (Rear)
4x USB 2.0 (Front)
2x USB 5Gbps Type A (Rear)
2x USB 5Gbps Type A (Front)
2x USB 10Gbps Type A (Rear)
1x USB 10Gbps Type C (Front)

LAN

Realtek® 8125BG 2.5G LAN

AUDIO

Realtek® ALC897 Codec
7.1-Channel High Definition Audio

INTERNAL IO

1x Power Connector(ATX_PWR)
1x Power Connector(CPU_PWR)
1x CPU Fan
1x Pump Fan
3x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x Com Port (JCOM)
2x Addressable V2 RGB LED connector (JARGB_V2)
2x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0 ports
2x USB 5Gbps Type A ports
1x USB 10Gbps Type C ports
